Iridium Certus 100 Devices

The Iridium Certus 100 service sits between Iridium’s Short Burst Data (SBD) service
and the higher throughput of Certus 700. It utilizes the L-Band frequency range, so
antennas can be small and lightweight, and the connection is resilient and stable.
Certus 100 offers IP data speeds of up to 88 Kbps.

The RockREMOTE Series

RockREMOTE delivers a reliable and flexible, IP or message-based, satellite communications solution for fixed, semi-fixed or mobile M2M / IoT applications worldwide.

Customers select between Ethernet, Wi-Fi or Serial RS232/485 for their communications interface requirements. All devices support the new Iridium Messaging Transport (IMT) service which materially lowers the cost of your transmissions, in addition to Iridium Certus 100 (22/88 Kbps).

RockREMOTE Mini OEM

RockREMOTE Mini

RockREMOTE Rugged

RockREMOTE

Form Factor

Integrator PCB

Externally Mounted

Externally Mounted

Internally DIN Rail Mounted

Dimensions

175 x 60 x 37 mm

182 x 75 x 53 mm

250 x 97 x 61 mm

193 x 120 x 117 mm

Weight

287 g

624 g

1.2 kg

1.26 kg

Environmental

No Rating

IP66

IP67

IP5x

Power Consumption

<30mW (sleep), <0.25W (idle), <7.5W (average transmit)

<30mW (sleep), <0.25W (idle), <7.5W (average transmit)

0W (sleep), 5W (idle), 9W (average transmit)

0W (sleep), 5W (idle), 9W (average transmit)

Iridium Certus Antenna

Various Approved Options

Various Approved Options

Various Approved Options

Various Approved Options

Satellite

Iridium Certus 100 (22/88 Kbps) + IMT (100 kB per message)

Iridium Certus 100 (22/88 Kbps) + IMT (100 kB per message)

Iridium Certus 100 (22/88 Kbps) + IMT (100 kB per message)

Iridium Certus 100 (22/88 Kbps) + IMT (100 kB per message)

Cellular

LTE Cat-4 & Cat-1

LTE Cat-4 & Cat-1

Interfaces

Ethernet (available on pin out), Serial RS232, RS485, GPIO (2xI, 2xO)

Ethernet, Serial RS232, RS485, GPIO (2xI, 2xO)

Ethernet, Wi-Fi, Serial RS232, RS485

Ethernet, Serial RS232, RS485/RS422 (optional Wi-Fi)

Bluetooth

Hosted Applications

Limited

Limited

Full

Full

MQTT & FTP Facades

Iridium-Global-Coverage-Map-2023

Iridium Certus 100 Information

  • Pole to pole coverage with no ‘line of sight’ challenges
  • Leverages the L-Band frequency – stable and resilient, not susceptible to ‘rain fade’
  • L-Band antennas are small and lightweight, ideal for portable and mobile use
  • Omni-directional antennas with no moving parts
  • IP data speeds of up to 88 Kbps, ideal for SCADA applications
  • Lower latency and less signal attenuation than BGAN M2M
  • Low power, small form factor equipment
  • Easy to deploy with no satellite pointing required.
Iridium Coverage Map

Iridium Certus 100 Service Plans and Pricing

For more information about our Certus 100 Service Plans, please visit our dedicated Certus 100 airtime page.

Plan:
Low Usage
Mid Usage
High Usage
Included Data:
1 MB
30 MB
200 MB
Price Per Month:
£30.00
£125.00
£553.00
Activation Fee:
£13.00
£13.00
£13.00
Overage Fee / MB:
£13.04
£6.52
£4.35
SKU:
AT-CER100-IOT-1MB-3-24
AT-CER100-IOT-30MB-12-24
AT-CER100-IOT-200MB-12-24
Plan:
Low Usage
Mid Usage
High Usage
Included Data:
1 MB
30 MB
200 MB
Price Per Month:
$35.00
$144.00
$636.00
Activation Fee:
$15.00
$15.00
$15.00
Overage Fee / MB:
$15.00
$7.50
$5.00
SKU:
AT-CER100-IOT-1MB-3-24
AT-CER100-IOT-30MB-12-24
AT-CER100-IOT-200MB-12-24

Benefits of Certus 100 Service

Is Certus 100 the best choice for your IoT connectivity challenge? We've outlined some of the key attributes of the service, but if you'd like any advice, please get in touch.

IP-Based for Easy Integration

It's easy to get going with the RockREMOTE device. It "takes the work out of the comms side for us which can be difficult between Arduino and Raspberry Pi equipment." The RockREMOTE offers dual-mode satellite and cellular airtime, too, so it's highly cost effective.

Satellites in Low Earth Orbit

Certus 100 utilizes Iridium’s low earth orbit (LEO) network, which provides pole-to-pole coverage, and has the benefit of lower latency (<1 second). Additionally, antennas do not have to be pointed to pick up Iridium satellites, which makes this service ideal for mountainous or wooded areas.

Supported by Industry Experts

Ground Control's support team are available to help you at any stage of your IoT connectivity project, from device and airtime selection through to installation, testing and lifetime support. No device leaves our premises without being thoroughly tested, and with the latest firmware installed.

Comparing Satellite IoT Connectivity

It’s tricky to compare airtime services because so much depends on how much data you need to send, but as a rough guide, we’ve put together the following comparison points. Get in touch if you’d like any help deciding what will work best for you.

Service:
Iridium SBD
Iridium Certus 100
Viasat IoT Pro (BGAN M2M)
Connection Type:
Message-Based
IP-Based
IP-Based
Typical Connection Speed:
270 / 320B per Message
22 / 88 Kbps
448 / 464 Kbps
Satellite Orbit:
Low Earth Orbit (LEO)
Low Earth Orbit (LEO)
Geostationary
Latency:
Very Low
Very Low
Low
Total Cost of Ownership:
Very Low
Medium
Low
Power Usage:
Very Low
Medium
Low
Connection Frequency:
On Demand
Frequently Connected
Frequently Connected
Great For:
Very small amounts of data from individual sensors
Fixed or mobile IoT applications which require IP connection
Fixed IoT applications with larger amounts of data to transfer via an IP connection

Is Iridium Certus 100 the right airtime for your project?

Ground Control are one of a very small number of Iridium partners chosen to design and build Iridium Certus 100-enabled hardware, and there’s very little we don’t know about the pros and cons of this service.

Please call or email us, or complete the form, if you’d like to discuss your project, and we’ll provide expert, impartial advice on the best hardware, airtime and service to meet your needs.
