Advanced secure communications
The i-Comm Secure provides a secure network tunnel for communication. Using a standard RS232/V24 interface with power via interface or external PSU. Its small size and light weight means it needs no additional fixing in most applications.
i-Comm uses Ground Control’s iPAM Intelligent IP application and data management system, providing an always-on link to the connected asset. iPAM manages addressing and routing to provide a static IP:Port for communication regardless of i-Comm address environment.
The service is secure and appears exactly the same as our Cellular service to customers, so the communication process is identical. Core services running on UK-located AWS Scalable Servers, with redundancy for high tier reliability.
- Replaces obsolescent PSTN services where cellular is not an option
- Secure encrypted serial to IP bridge and connection manager
- Transparent TCP/IP connection for full interoperability with existing systems
- IP Transport Layer Security and AES encryption
- WiFi connection. LAN expansion option (additional unit)
- Flexible powering options
- Secure, light touch configuration
- Remote configuration and status via app or browser
- Full management and analysis via iPAM platform
- Remote upgradeability
- Communication: IPv4/IPv6 stack with TCP and UDP protocols, and Wi proprietary secure communication technologies
- Encryption and security: TLS 1.2 and AES encryption
- Network interface: WiFi connection or LAN via separate secure WiFi / LAN bridge. Static IP or DHCP
- Interface: Industry standard 25 way D-Sub socket, V24 RXD, TXD, DCD, DTR, RTS, CTS, RI and DSR 1200 – 9600bps, even or no parity. Other configurations available on request
- Configuration: Local via serial port, remotely via browser and app
- Updates: Remote upgrade via iPAM system
- Enclosure: Custom moulded fire resistant ABS housing
- Weight: 90g
- Operating conditions: -30 to +75°C operating; –40 to +85°C storage. Humidity 0-95% non-condensing
- CE / UKCA Certification: EMC, LVD and all applicable standards
