I-CELL 1140 2G/LTE
iCell Elster 1140 provides remotely managed 4G, LTE-M, NB-IoT and legacy 2G connectivity for Elster A1140 and A1120 electricity meters.
Designed to fit beneath the A1140 series terminal cover, it connects directly to the meter for power and data. Flexible SIM options, remote provisioning, antenna diversity and over-the-air updates help reduce site visits across long-term metering deployments.
Key Capabilities
Purpose-built for reliable, remotely managed connectivity across long term electricity metering deployments.
4G Cat 1 bis, LTE-M, NB-IoT and legacy 2G connectivity
Purpose-built integration with Elster A1140 and A1120 meters
Direct power and data connection through the meter interface
Remote monitoring, provisioning and firmware updates over the air
Internal and external antenna support with automatic diversity
Designed for Elster Meter Integration
iCell Elster 1140 is designed specifically for the Elster A1140 meter range and also supports the A1120 dedicated meter interface. It fits beneath the A1140 series terminal cover and clips directly to the meter supports, avoiding the need for a separate external modem enclosure.
The device connects through the proprietary RJ12 meter interface, which provides both power and communications. This simplifies installation and reduces the amount of additional cabling and equipment required at the meter.
Resilient, Remotely Managed Connectivity
Support for current and legacy cellular technologies gives operators greater flexibility as network availability changes. External SIM and embedded SIM options, together with eUICC and iUICC capabilities, support remotely provisioned and resilient connectivity.
Device status and supported configuration functions can be managed remotely through a browser-based platform, while firmware-over-the-air support reduces the need to visit deployed meters for routine updates.
Product Specifications
Meter Integration
- Compatible Meters
- Elster A1140 and A1120
- Installation
- Fits beneath the A1140 series terminal cover and clips directly to the meter supports
- Meter Interface
- Elster proprietary interface via RJ12 connector
- Power Input
- Fully powered through the meter interface
- Enclosure
- Custom-moulded, fire-resistant ABS housing
Cellular Connectivity
- Supported Technologies
- 4G Cat 1 bis, LTE-M, NB-IoT and quad-band 2G
- LTE Bands
- B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B26 and B28
- 2G Bands
- B2, B3, B5 and B8
- LTE-M Speed
- Uplink up to 375 kbps; downlink up to 300 kbps
- NB-IoT Speed
- Uplink up to 62.5 kbps; downlink up to 21 kbps
- 2G Speed
- Uplink up to 236 kbps; downlink up to 296 kbps
- IP Support
- IPv4 and IPv6
- Transport Protocols
- TCP and UDP
- Additional Messaging
- SMS, where supported
SIM, Antenna and Management
- SIM Options
- External SIM and eSIM options, with eUICC and iUICC capability
- Antenna Options
- Integrated internal antenna and external antenna connection
- Antenna Operation
- Automatic diversity between internal and extern
- Local Configuration
- Through the metering port
- Remote Configuration
- Via browser or app
- Control
- AT-compatible commands and proprietary protocols
- Remote Updates
- Firmware over the air
Physical, Environmental and Compliance
- Standby Power
- 20 mW
- Power Saving Features
- Power Saving Mode and extended Discontinuous Reception
- Weight
- 90 g / 3.17 oz
- Operating Temperature
- -30°C to +75°C / -22°F to +167°F
- Storage Temperature
- -40°C to +85°C / -40°F to +185°F
- Operating Humidity
- 0-95% relative humidity, non-condensing
- Compliance
- RED, EMC, LVD and applicable standards
- Product Code
- P003-4G-A1140
