Multiple Use; Compact Design
Over 90% more compact than the previous model and featuring standardised connectors, the Iridium 9523N drives global communications in ways never thought possible.
From single or multi channel communication platforms for maritime, aviation and land mobile markets to highly capable, feature-enhanced handheld smart devices and unattended sensors, the Iridium Core 9523N module delivers cost effective satellite voice and data communications.
Contact us
Key Features
Tech Specification
- Pole-to-pole global coverage
- Single-board transceiver
- Voice, Circuit Switched Data and RUDICS
- Direct PCB integration
- Ultra compact form factor
- Standardised connectors
- Short Burst Data (SBD) capable
- FCC, Industry Canada, and CE approval
- Dimensions (LxWxH): 70.44mm x 36.04mm x 14.6mm (reservoir capacitors); 8.9mm (screen can)
- Operating Temperature: -30ºC to + 70ºC | Operating Humidity: ≤ 75% RH
- Frequency Range: 1616 MHz to 1626.5 MHz
- Input / Output Impedance: 50 Ω
- VBAT Power Input: Nominal Voltage +3.7 V | Voltage Limits +3.2 V to +6 V | Maximal Current 500 mA
- VBoost Power Input: Nominal Voltage +27 V | Absolute Maximal Voltage +35 V | Maximal Recommended Voltage +32 V | Minimal Voltage during Call Transmit Burst +10.5 V | Maximal Current 1 A
- Weight: 32g (0.07 lb)
- Storage Temperature: -40ºC to + 85ºC | Storage Humidity ≤ 93% RH
- Duplexing Method: TDD (Time Domain Duplex)
- Multiplexing Method: TDMA / FDMA
- VBAT Typical Current at Nominal +3.7 V: Standby Current 70 mA | Peak Current during Call 300 mA | Average Current during Call 110 mA
- VBoost Power Consumption: Typical Average Power during Call 2.3 W | Maximal Average Power during Call 3.1 W
